Low Noise Water Cooled Industrial Chiller 50HP 153.91KW/Hr With 4 Inlets 4 Outlets

Low Noise Water Cooled Industrial Chiller 50HP 153.91KW/Hr With 4 Inlets 4 Outlets

Brand Name: MINGO
Model Number: MG-50WS
MOQ: 1
Payment Terms: L/C, T/T, Western Union, MoneyGram
Detail Information
Place of Origin:
China
Certification:
ISO CE
Name:
Water Cooled Industrial Chiller
Cooling Capacity:
153.91KW/Hr
Cooling Method:
Water-cooled
Voltage:
3Ph-380/415V-50/60Hz
Compressor Type:
Hermetic Scroll Type Or Piston
Compressor Power:
37.5KW
Condensator Type:
Copper Tube Shell
Condensator CMS:
33.09-38.72 M3/h
Pump Power:
4KW
Pump Lift:
25m
Dimension:
2200mm-9200mm-1600mm (L-W-H)
Ambient Temperature:
3ºC-30ºC(can Be Customized)
Packaging Details:
Wooden box packaging
Highlight:

Low Noise Water Cooled Industrial Chiller

,

Water Cooled Industrial Chiller 50HP

,

Water Cooled Industrial Chiller 153.91KW/Hr

Product Description

Water Cooled Industrial Chiller 50HP 153.91KW/Hr Cooling Capacity 4 Inlets 4 Outlets



50HP  Water-Cooled Industrial Chiller


The 50HP Water-Cooled Industrial Chiller is a high-capacity, energy-efficient cooling solution designed for demanding industrial applications. With its innovative multi-compressor design, this chiller provides exceptional cooling performance and reliability, making it ideal for a variety of sectors, including manufacturing, chemical processing, and HVAC.



Key Features:



  • Triple Compressor Design: Utilizes three independent compressors for enhanced reliability and redundancy, allowing for flexible cooling capacity management and reduced energy consumption during partial loads.
  • High Efficiency: Engineered with advanced evaporators and condensers, maximizing heat exchange efficiency while minimizing operational costs.
  • Durable Construction: Built with robust materials to withstand harsh industrial environments, ensuring longevity and reduced maintenance needs.
  • User-Friendly Control System: Features a sophisticated digital control panel for real-time monitoring and precise temperature adjustments, enhancing operational efficiency.
  • Low Noise Operation: Designed for quiet performance, making it suitable for environments where noise levels need to be kept to a minimum.
  • Eco-Friendly Refrigerant: Uses environmentally safe refrigerants compliant with international standards, reducing the overall environmental footprint.



Specification:





Voltage 3/N/PE 380/220V 50Hz
Cooling capacity kW/h 50HZ-153.91 60HZ-180.07
Kcal 50HZ-132359 60HZ-154860
Compressor power kW 37.50
type Hermetic scroll type or piston
Refrigerant type R22, R404A, R407c, R134A
Condenser type Efficient copper tube shell and tube type
water flow m³/h 33.09-38.72
Pipe dimension G3"
Evaporator water solubility 0.560
water flow m³/h 26.48-30.98
Pipe dimension G3"

Pump



Power KW 4.0
Lift m 25
Protection device High pressure protection, low pressure protection, overload protection, antifreeze protection, flow protection
Ambient temperature ºC 3-room







Applications:



  • Manufacturing Processes: Ideal for various industrial applications that require consistent cooling to maintain optimal production conditions.
  • Chemical Processing: Supports temperature-sensitive reactions and processes, ensuring stability and safety throughout production.
  • Plastic Injection Molding: Provides reliable cooling for molds, enhancing cycle times and improving product quality.
  • HVAC Systems: Enhances cooling efficiency in large commercial and industrial facilities, contributing to energy savings and occupant comfort.



Benefits:



  • Enhanced Reliability: The three-compressor system ensures continuous operation, reducing the risk of downtime and improving overall productivity.
  • Cost-Effective Operation: Energy-efficient design leads to significant savings on utility costs, while durable construction minimizes maintenance and repair expenses.
  • Improved Cooling Performance: Consistent temperature management ensures high-quality outputs, reducing defects and enhancing customer satisfaction.
  • Sustainable Solution: Eco-friendly refrigerants support corporate sustainability goals, helping businesses meet environmental regulations and reduce their carbon footprint.







Upgrade your industrial cooling capabilities with our 50HP 3-Compressor Water-Cooled Industrial Chiller—where superior performance meets reliability, driving efficiency and productivity in your operations.
