Industrial Water Cooled Chiller Unit 80HP 90KW/Hr With Hermetic Compressor

Industrial Water Cooled Chiller Unit 80HP 90KW/Hr With Hermetic Compressor

Brand Name: MINGO
Model Number: MG-80WS
MOQ: 1
Detail Information
Place of Origin:
China
Certification:
ISO CE
Cooling Capacity:
90KW/Hr
Cooling Method:
Water-cooled
Voltage:
3Ph-380V-50Hz
Compressor Type:
Hermetic Scroll Type Or Piston
Compressor Power:
22KW
Condensator Type:
Copper Tube Shell
Condenser CMS:
21.3 M3/h
Pump Power:
3KW
Pump Lift:
22m
Dimension:
1750mm-760mm-1500mm (L-W-H)
Ambient Temperature:
3ºC-30ºC(can Be Customized)
Current A:
43.5
Name:
Water Cooled Industrial Chiller
Packaging Details:
Wooden box packaging
Highlight:

Industrial Water Cooled Chiller Unit

,

Industrial Water Cooled Chiller 80HZ

,

Water Cooled Chiller Unit 90KW/Hr

Product Description

Water Cooled Industrial Chiller 80HP 90KW/Hr Cooling Capacity Hermetic Compressor



80HP Water-Cooled Industrial Chiller


The 80HP Water-Cooled Industrial Chiller is a high-capacity, efficient cooling solution designed for large-scale industrial applications. With its advanced engineering and robust construction, this chiller ensures optimal temperature control, making it perfect for sectors such as manufacturing, chemical processing, and large commercial HVAC systems.



Key Features:



  • Exceptional Cooling Performance: Delivers powerful cooling capacity to manage substantial thermal loads, ensuring stable and efficient operation.
  • Energy-Efficient Design: Incorporates cutting-edge technology to reduce energy consumption while maximizing cooling output, resulting in significant cost savings on utilities.
  • Durable Construction: Built with high-quality, corrosion-resistant materials designed to withstand harsh industrial environments, ensuring longevity and reliability.
  • Advanced Control System: Features a sophisticated digital control panel for real-time monitoring, precise temperature adjustments, and easy integration into existing systems.
  • Low Noise Operation: Engineered for quiet performance, making it suitable for environments where sound levels need to be controlled.
  • Eco-Friendly Refrigerant: Utilizes environmentally safe refrigerants that comply with international standards, minimizing environmental impact and supporting sustainability initiatives.



Specification:



Voltage 3/N/PE 380/220V 50Hz
Cooling capacity kW/h 90
Kcal 85303
Compressor power kW 22.00
type Hermetic scroll type or piston
Refrigerant type R22, R404A, R407c, R134A
Condenser type Efficient copper tube shell and tube type
water flow m³/h 21.3
Pipe dimension 76mm
Evaporator water solubility 0.380
water flow m³/h 17.06-19.96
Pipe dimension 76mm
Pump Power KW 2.0
Lift m 22
Protection device High-pressure protection, low-pressure protection, overload protection, antifreeze protection, flow protection
Ambient temperature ºC 3-room





Applications:



  • Manufacturing Processes: Ideal for cooling machinery and maintaining optimal production conditions, enhancing efficiency and productivity.
  • Chemical Processing: Supports temperature-sensitive processes, ensuring stability and safety in chemical reactions.
  • Plastic Injection Molding: Provides efficient cooling for molds, improving cycle times and product quality.
  • HVAC Systems: Enhances cooling efficiency in large commercial and industrial facilities, improving occupant comfort and reducing energy costs.



Benefits:



  • Increased Reliability: Designed for continuous operation, the chiller minimizes the risk of downtime, enhancing overall productivity and efficiency.
  • Cost-Effective Operation: The energy-efficient design leads to lower operating costs, while durable construction reduces maintenance and repair expenses.
  • Improved Product Quality: Consistent temperature management ensures high-quality outputs, reducing defects and increasing customer satisfaction.
  • Sustainable Solution: Compliance with eco-friendly standards supports corporate sustainability goals, helping businesses achieve their environmental targets.





Elevate your industrial cooling capabilities with our 80HP Water-Cooled Industrial Chiller—where high performance meets reliability, driving efficiency and productivity in your operations.
