Quiet Operation Water Cooled Industrial Chiller 15HP 58.66KW/Hr

Quiet Operation Water Cooled Industrial Chiller 15HP 58.66KW/Hr

Brand Name: MINGO
Model Number: MG-15WD
MOQ: 1
Payment Terms: L/C, T/T, Western Union, MoneyGram
Detail Information
Place of Origin:
China
Certification:
ISO CE
Name:
Water Cooled Industrial Chiller
Cooling Capacity:
50HZ-50.14KW/Hr 60HZ-58.66KW/Hr
Cooling Method:
Water-cooled
Voltage:
3Ph-380V/415V-50Hz/60Hz
Compressor Type:
Hermetic Scroll Type Or Piston
Compressor Power:
11KW
Condenser Type:
Copper Tube Shell
Condenser CMS:
10.78-12.71 M3/h
Pipe Diameter:
G2''
Pump Power:
1.5KW
Pump Lift:
21.5m
Dimension:
1460mm-700mm-1400mm (L-W-H)
Ambient Temperature:
3ºC-43ºC(can Be Customized)
Packaging Details:
Wooden box packaging
Highlight:

Water Cooled Industrial Chiller 15HP

,

Water Cooled Industrial Chiller 58.66KW/Hr

,

Quiet Operation Water Cooled Industrial Chiller

Product Description

Water Cooled Industrial Chiller 15HP 58.66KW/Hr Cooling Capacity Wide Temperature Control Range



15HP Water-Cooled Industrial Chiller


The 15HP Water-Cooled Industrial Chiller is a reliable and efficient cooling solution designed for medium-sized industrial applications. Engineered for optimal performance, this chiller is ideal for various sectors, including manufacturing, food processing, and HVAC systems.



Key Features:



  • Robust Cooling Capacity: Delivers effective cooling performance, managing substantial thermal loads to maintain optimal operating conditions.
  • Energy-Efficient Design: Optimized to reduce energy consumption while maximizing cooling output, resulting in significant savings on utility costs.
  • Durable Construction: Built with high-quality materials that withstand challenging industrial environments, ensuring longevity and minimal maintenance.
  • Intuitive Control System: Features a user-friendly digital control panel for real-time monitoring and precise temperature adjustments, enhancing operational efficiency.
  • Quiet Operation: Designed for low noise levels, making it suitable for environments where sound control is essential.
  • Eco-Friendly Refrigerant: Utilizes environmentally safe refrigerants that comply with international standards, minimizing environmental impact.



Specification:





Voltage 3/N/PE 380/220V 50Hz
Cooling capacity kW/h 50HZ-50.14 60HZ-58.66
Kcal 50HZ-43120 60HZ-50451
Compressor power kW 11.00
type Hermetic scroll type or piston
Refrigerant type R22, R404A, R407c, R134A
Condenser type Efficient copper tube shell and tube type
water flow m³/h 10.78-12.61
Pipe dimension G2"
Evaporator water solubility 0.285
water flow m³/h 8.62-10.09
Pipe dimension G2"
Pump Power KW 1.5
Lift m 21.5
Protection device High-pressure protection, low-pressure protection, overload protection, antifreeze protection, flow protection
Ambient temperature ºC 3-room



Applications:



  • Manufacturing Processes: Ideal for cooling machinery and maintaining consistent operating conditions, enhancing overall productivity.
  • Food and Beverage Processing: Ensures proper temperature control during production and storage, adhering to safety and quality standards.
  • Plastic Injection Molding: Provides reliable cooling for molds, improving cycle times and product quality.
  • HVAC Systems: Supports effective cooling in commercial buildings, enhancing occupant comfort and reducing energy costs.



Benefits:



  • Increased Reliability: Designed for continuous operation, minimizing downtime and improving overall productivity.
  • Cost-Effective Operation: Energy-efficient performance leads to lower operational costs, while durable construction reduces maintenance expenses.
  • Improved Product Quality: Consistent temperature management ensures high-quality outputs, reducing defects and enhancing customer satisfaction.
  • Sustainability Commitment: Compliance with eco-friendly standards supports corporate sustainability initiatives, helping businesses meet their environmental goals.







Upgrade your industrial cooling solutions with our 15HP Water-Cooled Industrial Chiller—where efficiency meets reliability, driving performance and productivity in your operations.
