5HP Laser Water Chiller Air Cooled 14028 Kcal/Hr Cooling Capacity 3.75KW Compressor Power

5HP Laser Water Chiller Air Cooled 14028 Kcal/Hr Cooling Capacity 3.75KW Compressor Power

Brand Name: MINGO
Model Number: MG-05LC
MOQ: 1
Payment Terms: L/C, T/T, Western Union, MoneyGram
Detail Information
Place of Origin:
China
Certification:
ISO CE
Cooling Capacity:
50HZ-13.95KW/Hr 60HZ-16.32KW/Hr
Power Supply:
3Ph-380/450V-50/60HZ
Total Power:
4.86KW
Compressor Power:
3.75KW
Compressor Type:
Hermetic Scroll Type Or Piston
Fan CMS:
5000m³/s
Pump Power:
0.75KW
Pump Lift:
29m
Unit Dimension:
800mm-600mm-1190mm(L-W-H)
Condenser:
Efficient Brass Sets Corrugated Aluminum Fin
Packaging Details:
Wooden box packaging
Highlight:

5HP Laser Water Chiller

,

Laser Water Chiller Air Cooled

,

Laser Water Chiller 3.75KW

Product Description

Laser Chiller 5HP Air-Cooled 14028 Kcal/Hr Cooling Capacity 3.75KW Compressor Power



5HP Laser Chiller


The 5HP Laser Chiller is an advanced cooling solution specifically designed to maintain optimal operating temperatures for laser systems. This compact and efficient unit ensures reliable thermal management, enhancing the performance and longevity of laser equipment across various applications.



Key Features:



  • Efficient Cooling Capacity: Delivers precise temperature control to maintain optimal cooling for laser components, ensuring consistent performance and preventing overheating.
  • Compact Design: Space-saving footprint allows for easy installation in limited spaces, making it ideal for various industrial setups.
  • User-Friendly Control Panel: Features an intuitive interface for easy operation, monitoring, and adjustment of cooling parameters in real time.
  • Durable Construction: Built with high-quality materials to withstand industrial environments, ensuring reliability and long service life.
  • Low Noise Operation: Engineered for quiet performance, minimizing noise disruption in workspaces.
  • Integrated Safety Features:** Includes alarms and automatic shut-off mechanisms to protect the unit and connected equipment from potential issues.



Specification:





Voltage 3/N/PE 380/220V 50Hz
Cooling capacity kW/h 50HZ-13.95 60HZ-16.32
Kcal 50HZ-11990 60HZ-14028
Compressor power kW 3.75
type Hermetic scroll type or piston
Refrigerant type R22, R404A, R407c, R134A
Condenser type Efficient brass sets of corrugated aluminum fin
Fan air volume m³/h 5000
Evaporator type Immersion/plate / shell and tube High-Efficiency Heat Exchangers
water flow m³/h 2.40
Pipe dimension G1"
Pump Power KW 0.375
Lift m 24
Protection device High pressure protection, low pressure protection, overload protection, antifreeze protection, flow protection
Ambient temperature ºC 3-room







Applications:



  • Laser Cutting and Engraving: Maintains optimal temperature levels to ensure precise cutting and engraving, enhancing product quality and consistency.
  • Medical Laser Systems: Provides reliable cooling for medical lasers, ensuring safety and effectiveness during procedures.
  • 3D Printing: Supports laser systems used in additive manufacturing by preventing overheating and maintaining performance.
  • Research and Development: Ideal for laboratories and research facilities utilizing lasers for experiments, ensuring stable operating conditions.
  • Telecommunications: Used in fiber laser systems for telecommunications, optimizing performance and reliability.



Benefits:



  • Enhanced Performance: Ensures optimal cooling, improving the efficiency and output quality of laser systems.
  • Extended Equipment Lifespan: Reduces the risk of overheating, thereby prolonging the life of laser components and reducing maintenance costs.
  • Improved Productivity: Reliable cooling allows for uninterrupted operations, boosting overall productivity and workflow efficiency.
  • Cost-Effective Solution: Energy-efficient design reduces operational costs while providing effective thermal management.







Invest in the 5HP Laser Chiller for efficient cooling that enhances the performance and reliability of your laser systems. Experience the benefits of superior thermal management in your industrial applications with this essential cooling solution!
