High And Low Temperature Integrated Machine
Created with Pixso.

Powerful High And Low Temperature Integrated Machine 6kW Heating Capacity

Powerful High And Low Temperature Integrated Machine 6kW Heating Capacity

Brand Name: MINGO
Model Number: MG-05AHL
MOQ: 1
Payment Terms: L/C, T/T, Western Union, MoneyGram
Detail Information
Place of Origin:
China
Certification:
ISO CE
Cooling Capacity:
60HZ-18.32KW
Cooling Method:
Air-cooled
Heating Capacity:
6KW
Voltage:
3Ph-380V/415V-50Hz/60Hz
Refrigerant:
R22, R404A, R407c, R134A
Compressor Type:
Hermetic Scroll Type Or Piston
Compressor Power:
3.75KW
Condensator:
Brass Sets Corrugated Aluminum Fin
Pump:
0.75KW
Pump Lift:
34m
Ambient Temperature:
Customize
Dimension:
850mm-480mm-980mm (L-W-H)
Packaging Details:
Wooden box packaging
Highlight:

Powerful High And Low Temperature Integrated Machine

,

High And Low Temperature Integrated Machine 6kW

Product Description

Air-Cooled High and Low Temperature Integrated Machine with 6 kW Heating Capacity

The Air-Cooled High and Low Temperature Integrated Machine with 6 kW Heating Capacity is a powerful and versatile solution for industrial temperature control. This unit delivers 6 kW of heating power alongside efficient cooling, offering precise temperature regulation in a compact, air-cooled design. The system is optimized for industries that require both heating and cooling capabilities, without the need for a water supply, making it a cost-effective and low-maintenance option.

Key Features:

  • 6 kW Heating Capacity: Provides robust heating power to accommodate a variety of industrial applications requiring consistent high-temperature control.
  • Air-Cooled System: Eliminates the need for water, simplifying installation and reducing operating costs, making it a hassle-free solution.
  • Dual Functionality: Offers both heating and cooling in one unit, delivering flexible temperature control to suit various processes.
  • Wide Temperature Range: Designed to handle both high and low temperature needs, offering accurate and reliable performance across a broad spectrum.
  • Energy Efficient: Optimized for energy conservation, this system reduces operational costs while providing maximum temperature control.
  • User-Friendly Digital Controls: Intuitive digital control interface for easy temperature adjustments and real-time monitoring, enhancing user experience.
  • Durable Construction: Built with high-quality materials, ensuring longevity and reliable performance in demanding environments.
  • Compact Design: The integrated air-cooled system saves space, making it ideal for facilities with space constraints.
  • Low Noise Operation: Operates quietly, perfect for noise-sensitive environments such as labs, offices, or research centers.

Specification:

Cooling capacity KW/h 15.91(50hz)/18.32(60HZ)
Kcal/h 13690(50HZ)/16018(^)HZ
Heating capacity KW/h 6.0
Kcal/h 5064
Voltage   3N-380V-50HZ
Refrigerant   R22, R404A, R407c, R134A
Input power KW 16.75
Current A 30.1
Compressor power KW 3.75
Pump power KW 0.75
lift m 34
water volume m³/h 11.5
Condenser type   High efficiency copper tube shell and tube
cooling air volume m³/h 5200
heat exchange capacity KW 16.5
Evaporator type   Stainless steel
heat exchange capacity KW 14
Ambient temperature ºC customize



(Ps. Every specification can be customized.)



Applications:

  • Plastic Injection Molding: Ensures precise mold temperature control for optimal product quality and faster production cycles.
  • Pharmaceutical and Chemical Processing: Delivers stable temperature control for chemical reactions and pharmaceutical production processes.
  • Food and Beverage Industry: Maintains precise temperatures for processing and storage, ensuring food safety and quality.
  • Laboratories and R&D: Ideal for research, development, and testing environments that require accurate and stable temperature control.
  • HVAC Systems: Provides efficient heating and cooling solutions for large commercial and industrial spaces, supporting climate control needs.

Benefits:

  • High Heating Capacity: With 6 kW of heating power, this system can handle high-demand heating applications, ensuring reliability even in challenging industrial processes.
  • Cost Savings: The air-cooled system eliminates the need for water, reducing both initial infrastructure costs and ongoing maintenance expenses.
  • Energy Efficiency: Designed to optimize energy use, helping businesses lower their operating costs while maintaining precise temperature control.
  • Precise Temperature Management: Offers stable and consistent control over both heating and cooling, ensuring reliable performance in temperature-sensitive processes.
  • Low Maintenance: The air-cooled system requires minimal servicing, reducing downtime and improving operational efficiency.
  • Space-Saving Design: Compact unit that provides both heating and cooling, reducing the need for multiple machines and saving space.
  • Quiet Operation: Low-noise functionality ensures the system can operate in environments where noise levels must be kept to a minimum.
  • Eco-Friendly: Air-cooled technology reduces water consumption and operational waste, supporting more sustainable business practices.

The Air-Cooled High and Low Temperature Integrated Machine with 6 kW Heating Capacity is the ideal choice for industries requiring robust heating and efficient cooling in one reliable, easy-to-install system. With its powerful performance, cost-saving design, and precise temperature control, this machine is perfect for a wide range of industrial applications.
